HSM 405 H3 8WD

Thick trunk timber harvesting? Look no further than the HSM 405H3.

Development of the H3 had the aim of providing a harvester that is flexible and stable yet still agile. All technical components must be configured to ensure that high energy reserves are available for forest thinning operations with thick trunk timber or end use. Pure strength and stability for mechanised harvesting of thick trunk timber is what characterises the HSM 405H3.

Here are the basic technical details of our power pack:

engine 260kW / 1560Nm - hydraulics 536l/min at 1600rpm - steering angle 52° - Loglift L280 V110 crane with 280kNm lift torque - 195kNm pulling force. As an 8-wheeler or 6-wheeler with tilting comfort cab for ergonomic work and 800 sized tyres on balanced bogie axles, nothing stands in the way of efficient, environmentally-friendly operations in an optimised work environment. The HSM 405H3 is rounded off with harvester heads from Waratah or Logmax, which are designed for harvesting thick trunk timber.

The HSM 405H3 - at home with thick trunk timber.

Engine (6 cylinders):
  • VOLVO
    TAD872VE EU Stage IV / EPA T4f
    Engine output: 210 kW (286 PS) / 1700 rpm
    Torque: 1225 Nm from 1100-1600 rpm
    Max torque: 1235 Nm at 1350 rpm
    Engine capacity: 7.7 liter

    Option:

  • VOLVO
    TAD873VE EU Stage IV / EPA T4f
    Engine output: 235 kW (320 PS) / 1800 rpm
    Torque: 1300 Nm from 1200-1600 rpm
    Max torque: 1310 Nm at 1450 rpm
    Engine capacity: 7.7 liter
Transmission:
  • hydrostatic-mechanical
  • NAF 2-speed transfer gearbox
Axles:
  • NAF balanced portal tandem axles
  • At the front: 100 % selectable differential lock
  • At the rear: 100 % selectable differential lock
Brake:
  • 2-circuit brake, disk brakes running in an oil bath
  • Spring-loaded parking brake
Steering:
  • Articulated steering with 2 cylinders
  • 2 steering cylinders, 50° steering angle
Tyres:
  Size: Total width:
Series: 710/45-26,5 2880 mm Tapes and chains
Optional: 800/40-26,5 2980 mm only tapes
    3060 mm Tapes and chains
  600/55-26,5 2660 mm Tapes and chains
Tank capacity:
  • Diesel: 500 liters
  • AdBlue: 45 liters
  • Hydraulic fluid: 250 liters
Hydraulics:
  • Load sensing
  • Variable pump: Crane pump: 190 cm³
    Head pump: 190 cm³
    Flow rate: 532 l/min at 1400 rpm
    Pressure: up to 380 bar
  • Hydraulic fluid: Saturated, synthetic ester
    Panolin HLP SYNTH with Kleenoil
    Microfiltration; WGK 1
Cabin:
  • Height-adjustable at the front / rear +11° / -11° (restricted to -26°)
  • Bent Lexan windscreen
  • Windscreen wipers in the front and at the side
  • ROPS, FOPS, OPS tested
  • Tested safety cab
  • Air cushioned seat with seat heating
  • Hot water heating
  • Auxiliary heating with cooling water and hydraulic oil preheating
  • Air conditioner
  • Height-adjustable and rotatable (270°), front / rear +11° / -13°, lateral +/- 9°
  • Optional: Sun blinds
Electrical system / Instruments:
  • HSM Ecommand colour-display
  • 5 operator programs + factory setting
  • Diagnosis-tool and error-indication
  • Graphic support at parameter editing
  • Generator 110 A (28 A)
  • 2 service-free dry batteries á 75 Ah
Weight:
  • from 26200 kg

Torsion lock:
  • 2 hydraulic cylinders
Crane:
  • Mesera M280 V110
    Range: 11 m
    Gross lifting moment: 280 kNm
    Pivoting moment: 65 kNm
    Pivot angle: 260°
    Tilt angle: +24°/-30°
Aggregate:
  • Logmax 6000
    Felling diameter: 650 mm
    Delimbing diameter: 500 mm
    Gross lifting moment: 26.9 kN
    Max. feed force speed: 5.2 m/s
    Max. operating pressure: 280 bar
  • Control: DASA
  • Other aggregates on request
Series equipment:
  • 20 LED work lights on the cab, 4 work lights in front of the crane, 2 LED work lights on the crane column, 2 LED work lights on the rear frame, bogie lift front separately switchable, voltage converter on-board voltage 24 V to 12 V, end cushioning for crane and steering cylinder, radio, fire extinguisher, first-aid kit, warning triangle, tool set, bypass filter, Diesel fill pump, hydraulic fill pump, vacuum pump
Special accessories:
  • GPS system
  • Data transfer
  • Bogielift engine carriage
  • Attachement steep slope winch, traction constant 120 kN, max. 150 kN
  • Air compressor 24 V
  • Guard bracket bonnet
Crane M221 H100:
Lifting moment brutto 188 kNm
Swivering moment 43,6 kNm
Swivel angle 260°
Crane M240 H103:
Lifting moment brutto 240 kNm
Swivering moment 54 kNm
Swivel angle 260°
Crane M280 V110:
Lifting moment brutto 280 kNm
Swivering moment 65 kNm
Swivel angle 260°
Crane X270 H107:
Lifting moment brutto 270 kNm
Swivering moment 92 kNm
Swivering moment 260°
