HSM 208H2
Technical data 208H2
Engine:
-
VOLVO PENTA
TAD882VE EU Stage V
Power: 210 kW (286 HP) from 1700 rpm
Max. revolution: 1225 Nm from 1100 - 1600 rpm
Max. torque: 1255 Nm at 1400 rpm
Displacement: 7,7 liters
Transmission:
- NAF 2-speed transfer gearbox
- HSM High Speed Drive (71 series), 1st gear 0-14 km/h
Axles:
- NAF planetary axles
- Front: 100 % selectable differential lock
- Rear: 100 % selectable differential lock
Brake:
- 2-circuit brake, disk brake running in an oil bath
- Spring-loaded parking brake
Steering:
- Articulated steering with 2 cylinders
- 45° steering angle
Tyres:
Size: | Total width: | |
---|---|---|
Series: | 710/45-26,5 | 3000 mm |
Tank capacity:
- Diesel: 220 l + 65 l
- AdBlue: 45 l
- Hydraulic oil 170 l
Hydraulic system:
- Load sensing
- Variable pump (working pump):
flow rate: 304 l/min at 1600 rpm
pressure: up to max. 350 bar - Hydraulic oil:
saturated synthetic ester
Panolin HLP SYNTH with Kleenoil
Microfiltration; WGK 1
Cabin:
- Parallel pivoting cab
- ROPS, FOPS, OPS tested safety cab
- Swivel seat with pedals in the rear and the front
- Windscreen wipers in the front and the rear, optional side wipers
- Air cushioned seat with seat heating
- Hot water heating
- Air conditioner
Crane:
-
Mesera M221 H100 / H110
Range: 10 m / 11 m
Lifting moment gross: 188 kNm
Slewing torque: 43,6 kNm
Tiltable: +24°/-30°Optional:
-
Mesera M240 H103 / H111
Range: 10,3 m / 11,1 m
Lifting moment gross: 240 kNm
Slewing torque: 54 kNm
Tiltable: +22°/-30°
Aggregate:
- Logmax 6000
Felling diameter: 650 mm
Delimbing diameter: 500 mm
Max. feed force: 26,9 kN
Max. feed force speed: 4,2 m/s
Max. operating pressure: 280 bar
Weight: 1.330 kg - Control: LOG Mate
- Other aggregates on request
Electrics / Instruments:
- HSM Ecommand colour display
- 5 driving programs + factory setting
- Diagnostics function and error display
- Graphical support for editing parameters
- 110 A (28 V) generator
- 2 maintenance-free dry-cell batteries, each with 75 Ah
Weight:
-
20.800 kg (series)
Weight distribution:
Front axle: 60 %
Rear axle: 40 %
Torsion lock:
-
2 hydraulic cylinders
Standard equipment:
- 4 LED-working headlight at cabin
- 4 working headlights at crane
- Potential transformer, radio with CD, fire extinguisher, first aid kit, warning triangle, tool kit, cooling box
